TURNING13aWF RE 20%u00b020%u00b0 LUCDXLFDCONMSDMINRight-hand shownDimensionsDesignation DCONMS DMIN CDX(1) LU RE LF a WF IC908PICJ RT2020D20R05-10 .157 .079 .004 .3543 .002 .945 .067 - %u2022 PICJ RT2020D30R10-10 .157 .110 .008 .3543 .004 .945 .102 .024 %u2022 PICJ RT2020D40R10-16 .157 .157 .012 .5906 .004 1.181 .138 .059 %u2022 PICJ RT2020D50R15-20 .197 .197 .020 .7480 .006 1.378 .173 .075 %u2022 %u2022 Specify right- or left-hand bars %u2022 PICJ items are suitable for PICCO/MG PCO, PICCO ACE, SC-PICCO type holders only(1) Cutting depth maximum PICJ R/LT2020Inserts with Inner Coolant Channel for Internal Turning and Chamfering Next to the Bottom of Blind HolesaWF 20%u00b0 RE20%u00b0 LUCDXLFDCONMSDMINRight-hand shownDimensionsDesignation DCONMS DMIN CDX(1) LU RE LF a WF IC908PICCO R 050.20.2-10 .157 .079 .004 .3937 .002 .945 .067 - %u2022 PICCO R 050.20.3-10 .157 .110 .008 .3937 .004 .945 .102 .024 %u2022 PICCO R 050.20.4-16 .157 .157 .012 .6299 .004 1.181 .138 .059 %u2022 PICCO R 050.20.5-20 .197 .197 .020 .7480 .006 1.378 .173 .075 %u2022 %u2022 Specify right- or left-hand bars(1) Cutting depth maximum PICCO 050... PICCO 050.20...8%u00b0 20%u00b0PICCO R 050.20Inserts for Internal Turning and Chamfering Next to the Bottom of Blind Holes
